300_mW_25_MHz_AMPLIFIER

Published:2009/7/7 4:25:00 Author:May | From:SeekIC

Uses quarter-wavelength transmission line T3 in place of parallel-tuned traps to pass even-harmonic currentfreelywh＂e blocking odd harmonics Circuit canbe adapted to 300-mW、fvalkie-talkie for 6 or 10meters At 25 MHz、efficiency is 73％，－F, H，Raab，High-Efficiency RF Power Amplifiers，Ham Radio，Oct 1974，p 8-29.
