BA6395BFP-the servo-driven integrated circuit

Published:2011/5/12 2:35:00 Author:Borg | Keyword: servo-driven, integrated circuit | From:SeekIC

BA6996FP is a laser head servo-driven single door intergrated circuit, which is widely used in CD,VCD,SVCD and CVD players. 1. the internal circuit BA6359BPF contains 5 drive circuits, processing circuits of stopping input signals, transmission control circuits, stable voltage circuits, parameter voltage circuits and other stand-by circuits, and the internal circuits of it are listed in Figure 1. 2. pin functions and data BA6395BFP is in 28-pin dual in-line package, which is used in Xinke VCD-20C, and its pin functions and data are listed in Table 1.
