Current-comparator NORTON four op amp MC3301/3401

Published:2012/8/6 4:29:00 Author:Ecco | Keyword: Current-comparator, NORTON, four op amp | From:SeekIC

Figure (a)is simplifiedschematic diagram; Figure(b)is the inverting input amplifier circuit; Figure (c)is the noninverting input amplifier circuit.
