Medium-wave AM radio circuit

Published:2012/8/19 21:28:00 Author:Ecco | Keyword: Medium-wave , AM , radio | From:SeekIC

This circuit uses a FET for the preamp, and input signal is applied to the gate. In the drain loops, two loops have band-pass filter, and they use two tunable diodes for tuning. The resonant circuit determines the frequency, which is connected to pin 10 and 11 of IC.
