TA1216AN1--the multifunction audio signal process integrated circuit

Published:2011/6/9 2:35:00 Author:qqtang | Keyword: multifunction, audio signal, integrated circuit | From:SeekIC

TA1216AN1 is the multifunction audio signal process integrated circuit produced by Toshiba, which is widely used in all kinds of stereo system for processing the audio signals, such as TV stereos, domestic stereos, car stereos and multimedia stereos, etc.1.function featuresThe functions of TA1216AN1 are to complete high/low sound control, volume control, balance control and heavy low sound low-pass filtering and LEV switch, etc, and the internal circuit also includes D/A converter circuit, I2C general connector connector and input/output connector circuit,etc. The internal circuit is shown in Figure 1.
