TDA610lQ integrated block internal box circuit

Published:2011/5/11 2:10:00 Author:TaoXi | Keyword: integrated block, internal box | From:SeekIC

The TDA4665 and TDA4665T are designed as the baseband delay IC that is produced by the PHILIPS company, and it can be used in a variety of domestic multi-system TVs. The TDA4665 and TDA4665T use the switch capacitor technology, there are two filters to do one line time delay (64 us). The integrated block internal box circuit and the typical application in Haier 692-733AA TV are as shown in figure 12. This IC is in the 16-pin DP DIP package or 16-pin scaled type flat package, the pin functions and data of this circuitare as shown in table 15.
