3 Volts DC to 5 Volts DC Converter

Published:2013/8/21 21:25:00 Author:lynne | Keyword: 3 Volts DC to 5 Volts DC Converter | From:SeekIC

There are several ways to convert an AC voltage at a wall receptacle into the DC voltage required by a microcontroller. Traditionally, this has been done with a transformer and rectifier. However, in applications that involve providing a DC voltage to only the microcontroller and a few other low-current devices, transformer-based power supplies may not be cost effective. Presented here is the simple circuit of one boost converter, which can output steady 5VDC supply from a 3VDC input. This circuit can be used to power your 5V microcontroller/similar circuits from two standard AA cells (1.5V x2).
