HEF4052-the Intergrated Circuit of Analog Alternative Switches

Published:2011/5/12 0:04:00 Author:Borg | Keyword: Intergrated Circuit, Analog Alternative Switches | From:SeekIC

HEF4052 is an intergrated circuit of analog alternative switches, which is used to choose and shift signals in all kinds of screens of color TV sets, color CRTs,communication and stereos. 1.function features In fact, HEF4052 is a double 1-of-4 analog switches, which picks out one team of signals from two teams to deliver to corresponding circuit. 2. pin functions and data HEF4052 is encapsulated in dual in-line ways with 16-lead, which is used to shift audio in color TV sets of large screens.
