LM3886 Datasheet

Published:2013/10/15 20:36:00 Author:lynne | Keyword: LM3886 Datasheet | From:SeekIC

The LM3886 is a high-performance audio power amplifier capable of delivering 68W of continuous average power to a 4Ω load and 38W into 8Ω with 0.1% THD+N from 20Hz–20kHz. The performance of the LM3886, utilizing its Self Peak Instantaneous Temperature ( SPiKe™) protection circuitry, puts it in a class above discrete and hybrid amplifiers by providing an inherently, dynamically protected Safe Operating Area (SOA). SPiKe protection means that these parts are completely safeguarded at the output against overvoltage, undervoltage, overloads, including shorts to the supplies, thermal runaway, and instantaneous temperature peaks. LM3886 Applications component stereo compact stereo self-powered speakers surround-sound amplifiers high-end stereo TVs
