Three-Point Protection Circuit

Published:2011/7/5 5:58:00 Author:Robert | Keyword: Three-Point, Protection | From:SeekIC

The three-point protection circuit is shown in the picture. When there is a surge voltage flowing into the circuit, the gas discharge tube would guide the surge current to the underground. So that the equipments could get the protective effects. The picture shows the three-point protection circuit.
