PCF8581P I2C bus control memory integrated circuit diagram

Published:2011/5/5 20:44:00 Author:Ecco | Keyword: I2C , bus control, memory , integrated | From:SeekIC

PCF8581P is the I2C bus control electricity erasable reading memory integrated circuit produced by Philips, it is widely used in large screen color TV and other video, audio, air conditioners and other micro-computer control system. 1. Features of function PCF8581P IC is embedded CMOS 8 Kbit E2PROM read memory and I2C bus control interface circuit. Typical application circuit is shown as the figure. 2. Pin functions and data PCF8581P integrated circuit uses 8-pin dual in-line package, the pin functions and data are listed in Table. PCF8581P IC pin functions and data
