Automatic Gain Control – AGC circuit

Published:2012/10/10 1:52:00 Author:muriel | Keyword: Automatic, Gain Control | From:SeekIC

Automatic Gain Control or AGC is a circuit design which maintain the same level of amplification for sound or radio frequency. If the signal is too low the AGC circuit will increase (amplify) the level and if is to high will lower it to maintain a constant level as possible. The Automatic Gain Control principle is widely use in AM receivers and sometimes AGC is called an compressor-expander because it acts just like one.On the electroschematics.com site you can find some AGC schematics, just use the seach box. Mic preamplifier with AGC schematic
