Differential Combustible Gas Detector Circuit

Published:2011/5/17 5:45:00 Author:Robert | Keyword: Differential, Combustible Gas, Detector | From:SeekIC

In this circuit, BG1 and BG2's values should be as same as possible and it is best to choose differential pairs. Using this differential circuit the sensitivity of detecting gas could be 100×10^－6. The Differential Combustible Gas Detector Circuit is shown below.
