UNIJUNCIION_RING_COUNTER

Published:2009/7/14 3:56:00 Author:May | From:SeekIC

Provides switching for readout and control applications, including data display for airborne digital instrumentation. Q5-Q6 provide resetting.-F. W. Kear, Digital Control Uses Unijunction Transistors, Electronics, 34:18, p 79-80
