SHOCK_SPECTRUM_ANALYZER

Published:2009/7/16 22:45:00 Author:Jessie | From:SeekIC

Inexpensive peak memory unit has indefinitely long memory, to retain information long enough for dl channels to be recorded. Shock spec trum of input pulse is then defined by peak voltages across capacitors in all memory units. Output is d-c level for automatic recording or plotting.-D. F. Palmer, Shock Spectrum Analyzer, PEE, 11:3, p 118-119.
