The inverter circuit 14

Published:2011/7/16 4:26:00 Author:Christina | Keyword: inverter | From:SeekIC

Data: base coil 8-10 turns (two groups), Primary coil 18-24 turns (two groups), Subprime coil600-800 turns, the high power relay. The 39 and 2.7ohms resistabce is 2-4W; the 6uF capacitance's voltage is 1000V.
