MC9482 (electronic toy) remote control receiving decoder circuit

Published:2011/7/17 5:46:00 Author:Christina | Keyword: electronic toy, remote control, receiving, decoder | From:SeekIC

The MC9482 is designed as one kind of remote control receiving decoder circuit that can be used in the electronic toys. The internal circuit is composed of the oscillator, the frequency divider, the 6-bit register, the forward/back control logic circuit, the data detection circuit, the synchronous detection circuit, the address detection circuit, the left/right control logic circuit and the buffer. The matching model is MC9481.
