Three phase SCR trigger

Published:2011/4/25 3:05:00 Author:Nicole | Keyword: three phase SCR, trigger | From:SeekIC

XMA5000 series regulator sends out three phase SCR trigger pulse instruction, and it emits six SCR phase shift trigger or zero-crossing trigger control singal, it is used to control the main loop SCR trigger conduction. It adopts unique trigger control circuit, it can trigger 3A~1000A unidirectional or bidirectional SCR.
