CRYSTAL_CONTROLLED_PRR

Published:2009/7/16 1:22:00 Author:Jessie | From:SeekIC

Avalanche pulse generator used with 10.Mc AT.-cut crystal supplies nanosecond pulses with high sea bility and high repetition rate, for phase-locking microwave oscillcators and for generating vhf and uhf local oscillator signals.-J. N. Bridgeman, Crystal Accurately Controls Avalanche Pulse Generator, Electronics, 38:23, p 112-113.
