PROTECTED_OUTPUT_STAGE

Published:2009/7/19 23:32:00 Author:Jessie | From:SeekIC

High-voltage passivated mesa transistor in output stage of Japanese home radio is protected by silicon varistor R.-T. Kojima and M. Watanabe, When You're Second, You Try Harder, Electronics, 38:25, p 81-89.
