SIX_TRANSISTOR_72_V_1_W_BROADCAST

Published:2009/7/19 23:29:00 Author:Jessie | From:SeekIC

Nominal sensitivity is 150 microvolts per meter. Zero-signal battery drain is 10 ma.- Transistor Manual, Seventh Edition, General Electric Co., 1964, p 293.
