8530DYLF

16 LVPECL OUT BUFFER
Features

• 16 differential 2.5V LVPECL outputsCLK, nCLK input pair
• CLK, nCLK pair can accept the following differential input levels: LVDS, LVPECL, LVHSTL, SSTL, HCSL
• Maximum output frequency: 500MHz
• Translates any single-ended input signal to 2.5V
• LVPECL levels with a resistor bias on nCLK input
• Output skew: 50ps (maximum)
• Part-to-part skew: 250ps (maximum)
• Propagation Delay: 2ns (maximum)
• 3.3V core, 2.5V output operating supply
• 0°C to 70°C ambient operating temperature
• Industrial temperature information available upon request

Description
The ICS8530 is a low skew, 1-to-16 Differential-to-2.5V LVPECL Fanout Buffer and a member of the HiPerClockS? family of High Performance Clock Solutions from IDT. The CLK, nCLK pair can accept most standard differential input levels. The high gain differential amplifier accepts peak-to-peak input voltages as small as 150mV as long as the common mode voltage is within the specified minimum and maximum range.
Guaranteed output and part-to-part skew characteristics make the ICS8530 ideal for those clock distribution applications demanding well defined performance and repeatability.
