AIC1529

Pinout




Description

 The AIC1529 is a quad high-side power switch for self-powered and bus-powered Universal Serial Bus (USB) applications. Both high-side switches are MOSFET with 110mW RDS(ON), which meets USB voltage drop requirements for maximum transmission wire length.
 Multi-purpose open-drain fault flag output indicates over-current limiting, thermal shutdown, or undervoltage lockout for each channel. Output current of AIC1529 is typically limited to 1.3A, and the thermal shutdown functions of the power switches independently control their channel under overcurrent condition. Guaranteed minimum output rise time limits inrush current during hot plug-in as well as minimizing EMI and prevents the voltage at upstream port from dropping excessively.
