Purchase APT30D30B, In-stock APT30D30B From SeekIC.

MFG:APT  Package Cooled:TO-247 [B]  D/C:`06+(pb-free)

APT30D30B Product Image

APT Series Datasheet download

Five Points

Part Number: APT30D30B



MFG: APT

Package Cooled: TO-247 [B]

D/C: `06+(pb-free)



Urgent Purchase

APT30D30B Maximum Ratings

Symbol Characteristic / Test Conditions APT30D30B UNIT
VR Maximum D.C. Reverse Voltage 300 Volts
VRRM Maximum Peak Repetitive Reverse Voltage
VRWM Maximum Working Peak Reverse Voltage
IF(AV) Maximum Average Forward Current (TC = 110°C, Duty Cycle = 0.5) 30 Amps
IF(RMS) RMS Forward Current(Square wave, 50% duty) 70
IFSM Non-Repetitive Forward Surge Current (TJ = 45°C, 8.3ms) 320
TJ,TSTG Operating and StorageTemperature Range -55 to 150 °C
TL Lead Temperature: 0.063" from Case for 10 Sec 300

APT30D30B Features

• Ultrafast Recovery Times
• Soft Recovery Characteristics
• Popular TO-247 Package
• Low Forward Voltage
• High Blocking Voltage
• Low Leakage Current

APT30D30B Typical Application

• Anti-Parallel Diode-Switchmode Power Supply-Inverters
• Free Wheeling Diode-Motor Controllers-Converters
• Snubber Diode
• Uninterruptible Power Supply (UPS)
• Induction Heating
• High Speed Rectifiers

APT30D30B datasheet

APT30D30B
PDF/DataSheet Download

  • Datasheet: APT30D30B
  • File Size: 31647 KB
  • Manufacturer: ADPOW [Advanced Power Technology]
  • Click here to Download
