Part Number: BA3530FS



MFG: ROHM

Package Cooled: SSOP



Description: The BA3530FS is an H / P amplifier with internal secondary LPF and EVR circuits. When multibit output ...


Urgent Purchase

BA3530FS General Description


The BA3530FS is an H / P amplifier with internal secondary LPF and EVR circuits. When multibit output from a D / A converter is input, the secondary LPF outputs an audio signal. The amplifier circuit allows for line output and headphone output. The output level for headphones can be changed with the EVR circuit. This IC also has independent internal mute circuits for the left and right channels.

BA3530FS Features

1) Internal LPF, line amplifier and EVR.
2) Internal mute function.
3) Internal thermal shutdown circuit.
4) No attached components are needed for oscillation
  prevention, even at a load of 8W.
5) Mute function reduces the popping noises that can
  occur when the power is turned on and off.

BA3530FS Typical Application

CD-ROM drives and other products (with line and headphone output pins) that process digital audio signals
