Part Number: BA3575FS



MFG: N/A

Package Cooled: NA/

D/C: 09+

Description: The BA3575FS is a headphone driver with an AVC circuit that keeps the output below a fixed level. It f...


Urgent Purchase

BA3575FS General Description


The BA3575FS is a headphone driver with an AVC circuit that keeps the output below a fixed level. It features low current consumption, and low output noise, and is ideal for use in portable digital audio equipment.

BA3575FS Features

1) Low current consumption (when VCC = 2.4 V, the
   quiescent current is 4.9mA).
2) Suitable for use in digital audio equipment (voltage
  gain: GV = 11.8dB, output noise voltage: VNO = 102dBm typ.).
3) ATT circuit (gain switch).
4) AVC (Auto Volume Control) circuit, for output limiting.
5) Internal standby switch.
6) Internal mute switch.
7) Internal ripple filter.
8) No output coupling capacitor required.
9) Internal beep circuit.
10) SSOP-A20 package.

BA3575FS Typical Application

Portable CD players
