Part Number: BA3950A



MFG: ROHM

Package Cooled: SIP



Description: With 13.3V (external transistor required), 12V, 10V, and 5.6V outputs, the BA3950A power supply IC is best suited for C...


Urgent Purchase

BA3950A General Description


With 13.3V (external transistor required), 12V, 10V, and 5.6V outputs, the BA3950A power supply IC is best suited for CD player-equipped audio systems.

BA3950A Features

1) 13.3V (external transistor required), 12V, 10V, and
  5.6V outputs are built in (one output for each voltage).
2) Output current limit circuit protects the IC against short-circuiting damage.
3) Thermal protection circuit prevents heat damage to the IC.
4) Compact SIP-M12 package allows a large power dissipation.

BA3950A Typical Application

CD player-equipped audio systems
