Part Number: BA3963



MFG: ROHM

Package Cooled: SIP



Description: With 5V and 7V outputs and a reset output that detects the 5V output, the BA3963 power supply IC is best suited for CD ...


Urgent Purchase

BA3963 General Description


With 5V and 7V outputs and a reset output that detects the 5V output, the BA3963 power supply IC is best suited for CD player-equipped audio systems.

BA3963 Features

1) A 5V output, a 7V output, and a reset output are built in.
2) All output circuits use a PNP transistor with a low saturation voltage.
3) Current limit circuit protects the IC against short-circuiting damage.
4) Thermal protection circuit prevents heat damage to the IC.
5) Compact SIP-M12 package allows a large power dissipation.

BA3963 Typical Application

CD player-equipped audio systems
