General Description
BA8201 General Description
The BA8201 and BA8201F are ICs with a choke coil action, capable of extracting the DC current from a telephone line while maintaining a high inductance on the telephone line side. This eliminates the need for a choke coil, and facilitates use of the telephone set line in a variety of applications.
BA8201 Maximum Ratings
| Parameter | Symbol | Limits | Unit |
| Power supply voltage | Vcc |
18 | V |
| Power dissipation | Pd | 800(BA8201)*1 | mW |
| 450(BA8201F)*2 | |||
| Operating temperature | Topr | -20~+75 | |
| Storage temperature | Tstg | -55~+125 |
BA8201 Features
Corresponds to choke coil of several henries.
Extracts DC current while maintaining high inductance on telephone line side.
Capable of extracting large output current.
Wide dynamic range.
Two output voltage modes available for selection.
Line voltage seek mode
Constant voltage mode
DIP 8 and SOP 8 pin packages available.
Extracts DC current while maintaining high inductance on telephone line side.
Capable of extracting large output current.
Wide dynamic range.
Two output voltage modes available for selection.
Line voltage seek mode
Constant voltage mode
DIP 8 and SOP 8 pin packages available.
BA8201 Typical Application
Household telephones
BA8201 Connection Diagram
BA8201
