Purchase BF959, In-stock BF959 From SeekIC.
MFG:ON Semiconductor Category:Discrete Semiconductor Products
Part Number: BF959
Category: Discrete Semiconductor Products
MFG: ON Semiconductor
Descriptions: TRANS RF NPN 20V 100MA TO-92
- Table of contents:
BF959
-
Suppliers
DataSheet
General Description
BF959 General Description
TRANS RF NPN 20V 100MA TO-92
BF959 Parameters
| Technical/Catalog Information | BF959 |
| Vendor | ON Semiconductor |
| Category | Discrete Semiconductor Products |
| Frequency - Transition | 700MHz |
| Noise Figure (dB Typ @ f) | 3dB @ 200MHz |
| Current - Collector (Ic) (Max) | 100mA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 35 @ 5mA, 10V |
| Transistor Type | NPN |
| Voltage - Collector Emitter Breakdown (Max) | 20V |
| Gain | - |
| Power - Max | 625mW |
| Compression Point (P1dB) | - |
| Package / Case | TO-92-3, TO-226AA (Straight Leads) |
| Packaging | Bulk |
| Drawing Number | * |
| Lead Free Status | Contains Lead |
| RoHS Status | RoHS Non-Compliant |
| Other Names | BF959 BF959 |
BF959
PDF/DataSheet Download
- Datasheet: BF959
- File Size: 114124 KB
- Manufacturer: ONSEMI [ON Semiconductor]
- Click here to Download
