CEM-1606

Driver Circuitry: Transducer, Externally Driven
Input Type: zero-peak Signal
Operating Mode: Continuous
Mounting Type: Through Hole
Termination: PC Pins
Packaging: Bulk
Series: CEM
Manufacturer: CUI Inc
Technology: Magnetic
Frequency: 2.048kHz
Current - Supply: 50mA
Washable: Yes
Voltage - Rated: 6Vo-p
Voltage Range: 3 ~ 12V
Sound Pressure Level: 80dB @ 6V, 10cm
Size / Dimension: Circular - 16.00mm Dia x 14.50mm H


Specifications

recommended circuits: click here

rated voltage: 6.0Vo-p

operating voltage: 3-12Vo-p

mean current: 50mA

coil resistance: 50Ω ±7.0

coil impedance: 110Ω

sound pressure level: 85dB

rated frequency: 2048 Hz ±200

operating temperature: -20 to +60°C

storage temperature: -30 to +70°C

diameter: 16.0 mm

depth: 14.0 mm

weight: 4.6 grams

termination: PC pins

640){this.height=this.height*640/this.width;this.width=640;}' border="0" alt=" Connection Diagram">

Parameters:

Technical/Catalog Information	CEM-1606
Vendor	CUI Inc
Category	Zspecial
Sensitivity	*
Voltage - Rated	*
Current	*
Type	*
Size / Dimension	*
Frequency	*
S/N Ratio	*
Filter Type	*
Impedance	*
Termination	*
Direction	*
Port Location	*
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CEM 1606 CEM1606 102 1113 ND 1021113ND 102-1113
