CY2040-3
-
Suppliers
DataSheet
General Description
CY2040-3 Maximum Ratings
Supply Voltage ........................................................................... 0.5V to +7.0V
Input Voltage .......................................................................0.5V to V24M +0.5
Storage Temperature(Non-Condensing) ..............................55°C to +150°C
Junction Temperature.............................................................................+150°C
Static Discharge Voltage........................................................................ > 2000V
Input Voltage .......................................................................0.5V to V24M +0.5
Storage Temperature(Non-Condensing) ..............................55°C to +150°C
Junction Temperature.............................................................................+150°C
Static Discharge Voltage........................................................................ > 2000V
CY2040-3 Features
• Precision RTC 32 kHz and 24 MHz output
• Power-down mode (32 kHz on) is < 50 uA
• Suspend mode (V24M = off) is typically 5 uA
• Low RMS period Jitter (< 40 ps)
• 16-pin TSSOP package
• 3.3V + 5% Voltage Supply
• CY2040-2 multiplier 32.000 kHz × 750 = 24.0 MHz (requires a single 32.000 kHz crystal)
• CY2040-3 enables the 32 kHz and 24.0 MHz oscillators (requires a 32.768 kHz and 24.000 MHz crystal)
• Power-down mode (32 kHz on) is < 50 uA
• Suspend mode (V24M = off) is typically 5 uA
• Low RMS period Jitter (< 40 ps)
• 16-pin TSSOP package
• 3.3V + 5% Voltage Supply
• CY2040-2 multiplier 32.000 kHz × 750 = 24.0 MHz (requires a single 32.000 kHz crystal)
• CY2040-3 enables the 32 kHz and 24.0 MHz oscillators (requires a 32.768 kHz and 24.000 MHz crystal)
CY2040-3 Connection Diagram
CY2040-3
PDF/DataSheet Download
- Datasheet: CY2040-3
- File Size: 68651 KB
- Manufacturer: CYPRESS [Cypress Semiconductor]
- Click here to Download
