Features: • 2.5V or 3.3V operation• Split output bank power supplies• Output frequency range: 6 MHz to 200 MHz• 45 ps typical cycle-cycle jitter• ± 2% max output duty cycle• Selectable output drive strength• Selectable positive or negative edge synchroniza...
CY7B995: Features: • 2.5V or 3.3V operation• Split output bank power supplies• Output frequency range: 6 MHz to 200 MHz• 45 ps typical cycle-cycle jitter• ± 2% max output duty c...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The CY7B995 RoboClock® is a low-voltage, low-power, eight-output, 200-MHz clock driver. CY7B995 features output phase programmability which is necessary to optimize the timing of high-performance computer and communication systems.
The user can program both the frequency and the phase of the output banks through nF[0:1] and DS[0:1] pins. The adjustable phase CY7B995 feature allows the user to skew the outputs to lead or lag the reference clock. Any one of the outputs can be connected to feedback input to achieve different reference frequency multiplication and divide ratios and zero input-output delay.
The CY7B995 also features split output bank power supplies which enable the user to run two banks (1Qn and 2Qn) at a power supply level different from that of the other two banks (3Qn and 4Qn). Additionally, the three-level PE/HD pin controls the synchronization of the output signals to either the rising or the falling edge of the reference clock CY7B995 and selects the drive strength of the output buffers. The high drive option (PE/HD = MID) increases the output current from ± 12 mA to ± 24 mA.
