CY7C63723C-SXC

Maximum Operating Temperature : + 70 C
Minimum Operating Temperature : 0 C
Mounting Style : SMD/SMT
Packaging : Tube
Package / Case : SOIC-18
Product : USB and PS/2 Controller
Number of I/Os : 12
Operating Supply Voltage : 11 V


Description

The CY7C63723C-SXC is designed as one kind of low-speed USB peripheral controller that can be used in (1)PC HID devices: mice (optomechanical, optical, trackball); (2)gaming: joysticks and game pad; (3)general purpose such as the barcode scanners, POS terminal, consumer electronics, toys, remote controls and security dongles. Also the CY7C63723C-SXC includes an integrated USB serial interface engine (SIE) that allows the chip to easily interface to a USB host.

Features of the CY7C63723C-SXC are:(1)Advanced development tools based on Cypress MicroSystems PSoC tools;(2)USB 2.0-USB-IF certified (TID # 40000085);(3)Watchdog timer (WDT);(4)12-bit Programmable Interval Timer with interrupts;(5)Low voltage detection with user configurable threshold voltages;(6)Operating voltage from 4.0V to 5.5 VDC;(7)Operating temperature from 070°C;(8)Available in 16 and 18-pin PDIP; 16, 18, and 24-pin SOIC; 24-pin QSOP, and 32-pin QFN packages;(9)Industry standard programmer support;(10)125 mA 3.3V voltage regulator powers external 3.3V devices.

The absolute maximum ratings of the CY7C63723C-SXC can be summarized as:(1)Storage Temperature:40°C to +90°C;(2)Ambient Temperature with Power Applied:0°C to +70°C;(3)Supply Voltage on VCC Relative to VSS:0.5V to +7.0V;(4)DC Input Voltage:0.5V to +VCC+0.5V;(5)DC Voltage Applied to Outputs in High-Z State: 0.5V to +VCC+0.5V;(6)Latch-up Current: 200 mA;(7)Static Discharge Voltage: 2200 V;(8)Power Dissipation: 300 mW;(9)Maximum On-chip Power Dissipation on any GPIO Pin: 50 mW;(10)Maximum Total Sink Current into Port 0 and Port 1 pins: 70 mA. If you want to know more information such as the electrical characteristics about it, please download the datasheet in www.seekic.com or www.chinaicmart.com .

Parameters:

Technical/Catalog Information	CY7C63723C-SXC
Vendor	Cypress Semiconductor Corp
Category	Integrated Circuits (ICs)
Package / Case	18-SOIC
Packaging	Tube
Applications	USB Microcontroller
Controller Series	CY7C637xx
Core Processor	M8B
Program Memory Type	OTP (8 kB)
RAM Size	256 x 8
Number of I /O	10
Interface	PS2, USB
Voltage - Supply	3.5 V ~ 5.5 V
Operating Temperature	0°C ~ 70°C
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	CY7C63723C SXC CY7C63723CSXC 428 1855 ND 4281855ND 428-1855
