E102Z

Features: • Temperature coefficient of resistance (TCR):- 55 to + 125 , + 25 ref. 0.2 ppm/ typical• Rated power: to 0.3 W at + 125 , 0.6 W at + 70 • Tolerance: ± 0.005 %• Load life stability: to ± 0.005 % at 70 , 2000 h at rated power• Resistance range: 100 k to 250...

product image

E102Z Picture
See larger image
SeekIC No. : 004330510 Detail

E102Z: Features: • Temperature coefficient of resistance (TCR):- 55 to + 125 , + 25 ref. 0.2 ppm/ typical• Rated power: to 0.3 W at + 125 , 0.6 W at + 70 • Tolerance: ± 0.005 %• L...

E102Z Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
E102Z
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Temperature coefficient of resistance (TCR):
- 55 to + 125 , + 25 ref. 0.2 ppm/ typical
• Rated power: to 0.3 W at + 125 , 0.6 W at + 70
• Tolerance: ± 0.005 %
• Load life stability: to ± 0.005 % at 70 , 2000 h at rated power
• Resistance range: 100 k to 250 k (higher and lower
values of resistance are available)
• Electrostatic discharge (ESD) above 25 000 V
• Non inductive, non capacitive design
• Rise time: 1 ns without ringing
• Current noise: < - 40 dB
• Thermal EMF: 0.05 V/ typical
• Voltage coefficient < 0.1 ppm/V
• Low inductance: < 0.08 H typical
• Non hot spot design
• Terminal finishes available: lead (Pb)-free
tin/lead alloy
• Matched sets are available on request
(TCR tracking: to 0.5 ppm/)




Description

Ultra High Precision Bulk Metal® Z-Foil Extended Value Range Resistor, with TCR of 0.2 ppm/°C, PCR of 5 ppm Rated Power, Tolerance to 0.005 %, and Power Rated at 0.6 W

The Z-foil technology provides a significant reduction of the resistive component´s sensitivity to ambient temperature variations (TCR) and applied power changes (PCR).

Designers can now guarantee a high degree of stability and accuracy in fixed-resistor applications using solutions based on Vishay´s revolutionary Z-foil technology.

The E102Z (0.150" lead spacing) and E102JZ (0.200" lead spacing) extends the range of the ultra high precision Z201 and Z201L.

Our application engineering department is available to advise and to make recommendations. For non-standard technical requirements and special applications, please contact us.
