FDC5612

Transistor Polarity : N-Channel
Gate-Source Breakdown Voltage : +/- 20 V
Mounting Style : SMD/SMT
Packaging : Reel
Maximum Operating Temperature : + 150 C
Drain-Source Breakdown Voltage : 60 V
Configuration : Single Quad Drain
Continuous Drain Current : 4.3 A
Package / Case : SSOT-6
Resistance Drain-Source RDS (on) : 0.055 Ohms


Features:

• 4.3 A, 60 V.  R _DS(ON)  = 0.055 W  @ V_GS = 10 V
                       R _DS(ON)  = 0.064 W  @ V_GS =  6 V
• Low gate charge (12.5nC typical).
• Fast switching speed.
• High performance trench technology for extremely low  R _DS(ON)
• SuperSOTTM-6 package: small footprint (72% smaller  than standard SO-8); low profile (1mm thick).


Specifications

Symbol	Parameter	Ratings	Units
VDSS	Drain-Source Voltage	80	V
VGSS	Gate-Source Voltage	± 20	V
ID,	Drain Current - Continuous  (Note 1a)	4.3	A
	Drain Current - Pulsed	20
PD	Power Dissipation for Single Operation (Note 1a)                                                               (Note 1b)	1.6	W
		0.8
TJ, Tstg	Operating and Storage Junction Temperature Range	-55 to +150	°C

Description

This FDC5612 N-Channel MOSFET has been designed specifically to improve the overall efficiency of DC/DC converters using either synchronous or conventional switching PWM controllers.

These FDC5612 MOSFETs feature faster switching and lower gate charge than other MOSFETs with comparable R_DS(ON) specifications.

The result is a MOSFET FDC5612 that is easy and safer to drive (even at very high frequencies), and DC/DC power supply designs with higher overall efficiency.

Parameters:

Technical/Catalog Information	FDC5612
Vendor	Fairchild Semiconductor (VA)
Category	Discrete Semiconductor Products
Mounting Type	Surface Mount
FET Polarity	N-Channel
Drain to Source Voltage (Vdss)	60V
Current - Continuous Drain (Id) @ 25° C	4.3A
Rds On (Max) @ Id, Vgs	55 mOhm @ 4.3A, 10V
Input Capacitance (Ciss) @ Vds	650pF @ 25V
Power - Max	800mW
Packaging	Cut Tape (CT)
Gate Charge (Qg) @ Vgs	18nC @ 10V
Package / Case	SSOT-6
FET Feature	Logic Level Gate
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	FDC5612 FDC5612 FDC5612CT ND FDC5612CTND FDC5612CT
