Purchase FDP19N40, In-stock FDP19N40 From SeekIC.

MFG:Fairchild Semiconductor  Category:Discrete Semiconductor Products

FDP19N40

FDP Series Datasheet download

Five Points

Part Number: FDP19N40

Category: Discrete Semiconductor Products

MFG: Fairchild Semiconductor





Descriptions: MOSFET N-CH 400V TO-220

Price Break

1
10
100
250
500
1000
2500

Unit Price

2.33000
1.86000
1.39500
1.30200
1.25550
1.20900
1.19040

Extended Price

2.33
18.60
139.50
325.50
627.75
1209.00
2976.00

(All prices are in USD) Prices for reference only
Urgent Purchase

FDP19N40 General Description

MOSFET N-CH 400V TO-220

FDP19N40 Parameters

Technical/Catalog InformationFDP19N40
VendorFairchild Semiconductor
CategoryDiscrete Semiconductor Products
Mounting TypeThrough Hole
FET PolarityN-Channel
Drain to Source Voltage (Vdss)400V
Current - Continuous Drain (Id) @ 25° C19A
Rds On (Max) @ Id, Vgs240 mOhm @ 9.5A, 10V
Input Capacitance (Ciss) @ Vds 2115pF @ 25V
Power - Max215W
PackagingTube
Gate Charge (Qg) @ Vgs40nC @ 10V
Package / CaseTO-220
FET FeatureStandard
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names FDP19N40
