Features: • This Circuit is Processed in Accordance to MIL-STD-883 and is Fully Conformant Under the Provisions of Paragraph 1.2.1.• Low Offset Voltage. . . . . . . . . . . . .60mV (Max) 10mV (Typ)• Low Offset Voltage Drift . . . 0.6mV/ (Max) 0.1mV/ (Typ)• High Voltage Gain...
HA-5177_883: Features: • This Circuit is Processed in Accordance to MIL-STD-883 and is Fully Conformant Under the Provisions of Paragraph 1.2.1.• Low Offset Voltage. . . . . . . . . . . . .60mV (Max)...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
DescriptionThe HA-5002/883 is a monolithic, wideband, high slew rate, high output current, buffer ...
Features: • This Circuit is Processed in Accordance to MIL-STD-883 and is Fully Conformant U...
Voltage Between V+ and V- Terminals . . . . . . . . . . . . . . . . . . . 44V
Differential Input Voltage (Note 1) . . . . . . . . . . . . . . . . . . . . . . . 7V
Voltage at Either Input Terminal . . . . . . . . . . . . . . .. . V+ to VInput
Current. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . . . . . .25mA
Output Current . . . . . . . . . . . . . . . . . . .Full Short Circuit Protection
Junction Temperature (TJ) . . . . . . . . . . . . . . . . . . . . . . . . . . +175
Storage Temperature Range . . . . . . . . . . . . . . . . . -65 to +150
ESD Rating. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . <2000V
Lead Temperature (Soldering 10s) . . . . . . . . . . . . . . . .. . . . +300
CAUTION: Stresses above those listed in "Absolute Maximum Ratings" may cause permanent damage to the device. This is a stress only rating and operation of the device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
The HA-5177/883 is a monolithic, all bipolar, precision operational amplifier, utilizing Intersil Dielectric Isolation and advance processing techniques. This design features a combination of precision input characteristics, wide gain bandwidth (2MHz) and high speed (0.5V/ms min) and is an improved version of the HA-5135/883.
The HA-5177/883 uses advanced matching techniques and laser trimming to produce low offset voltage (10mV typ, 60mV max) and low offset voltage drift (0.1mV/ typ, 0.6mV/ max). This design also features low voltage noise (9nV/Hz typ), Low current noise (0.32pA/Hz typ), nanoamp input currents, and 126dB minimum gain.
These outstanding features of HA-5177/883 along with high CMRR (140dB typ, 110dB min) and high PSRR (135dB typ, 110dB min) make this unity gain stable amplifier ideal for high resolution data acquisition systems, precision integrators, and low level transducer amplifiers.
