HE12-1A83-02: Reed Relay 1 Form A 12 V High Voltage PCB

HE12-1A83-02 Data Sheet

US $ 19.96~22.36 / Piece | Get Latest Price

Part Number:: HE12-1A83-02
Mfg:: MEDER electronic
Supply Ability:: 5000

Price Break

Qty
0~1
1~10
10~25
25~100

Unit Price
$22.36
$21.56
$20.74
$19.96

Processing time
15 Days
15 Days
15 Days
15 Days

View more price & deliveries

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

HE12-10.2-A evaluate
Linear and Switching Power Supplies 12V/10.2A OUTPUT
HE12-10.2-A+ evaluate
Linear and Switching Power Supplies 12V 10.2A
HE12-10.2-A+G evaluate
US $87.68 - 94.45 / Piece

Linear and Switching Power Supplies 12V 10.2A

Product Details

Quick Details

Contact Form :	1 Form A (SPST-NO)	Coil Voltage :	12 VDC
Maximum Switched Power :	50 W	Maximum Switched Current :	3 A
Coil Suppression Diode :	No	Coil Resistance :	260 Ohms

Description

Termination Style :
Contact Form : 1 Form A (SPST-NO)
Coil Suppression Diode : No
Coil Voltage : 12 VDC
Maximum Switched Power : 50 W
Maximum Switched Current : 3 A
Coil Resistance : 260 Ohms

Features:

Power switching up to 50 W available
Special pin outs available
1 Form A and 1 Form B are standard
Various case sizes and cable lengths available
> 26 mm spacing between contact and coil available

Application

• High voltage test sets
• Cable testers
• Medical equipment (RF surgery)

Description

High voltage Reed Relays for PCB mounting suitable for switching up to 7.5 kVDC and breakdown voltage up to 10 kVDC. HE12-1A83-02 series is available with high voltage cables. Standard relays available in 1 Form A and 1 Form B switching configurations.

Parameters:

Technical/Catalog Information	HE12-1A83-02
Vendor	MEDER electronic
Category	Relays
Relay Type	Reed
Mounting Type	Through Hole
Termination Style	PC Pin
Circuit	SPST-NO (1 Form A)
Contact Rating @ Voltage	3A @ 7500VAC/DC
Coil Voltage	12VDC
Control Off Voltage (Min)	1.8 VDC
Control On Voltage (Max)	8.4 VDC
Coil Current	47.9mA
Coil Type	Standard
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	HE12 1A83 02 HE121A8302
