Purchase IMH3A, In-stock IMH3A From SeekIC.
MFG:ROHM D/C:3000
- Table of contents:
IMH3A
-
Suppliers
DataSheet
General Description
IMH3A Maximum Ratings
Parameter |
Symbol |
Limits |
Unit |
|
| Collector-base voltage | VCBO |
50 |
V |
|
| Collector-emitter voltage | VCEO |
50 |
V |
|
| Emitter-base voltage | VEBO |
5 |
V |
|
| Collector current | IC |
100 |
mA |
|
| Collector power dissipation |
EMH3,UMH3N | PC |
150(TOTAL) |
mW |
| IMH3A | 300(TOTAL) |
|||
| Junction temperature | Tj |
150 |
°C |
|
| Storage temperature | Tstg |
-55~+150 |
°C |
|
IMH3A Features
1) Two DTAK13Ts chips in a EMT or UMT or SMT package.
2) Mounting possible with EMT3 or UMT3 or SMT3 automatic mounting machines.
3) Transistor elements are independent, eliminating interference.
2) Mounting possible with EMT3 or UMT3 or SMT3 automatic mounting machines.
3) Transistor elements are independent, eliminating interference.
IMH3A
PDF/DataSheet Download
- Datasheet: IMH3A
- File Size: 194380 KB
- Manufacturer: ROHM [Rohm]
- Click here to Download
