IRF7380PBF

MOSFET

product image

IRF7380PBF Picture
See larger image
SeekIC No. : 00153156 Detail

IRF7380PBF: MOSFET

IRF7380PBF Data Sheet

floor Price/Ceiling Price

US $ .29~.81 / Piece | Get Latest Price
Part Number:
IRF7380PBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.81
  • $.5
  • $.34
  • $.29
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/4/28

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 80 V
Gate-Source Breakdown Voltage : 20 V Continuous Drain Current : 3.6 A
Resistance Drain-Source RDS (on) : 73 m Ohms Configuration : Dual
Maximum Operating Temperature : + 150 C Mounting Style : SMD/SMT
Package / Case : SOIC-8 Packaging : Tube

Description

Transistor Polarity : N-Channel
Mounting Style : SMD/SMT
Maximum Operating Temperature : + 150 C
Packaging : Tube
Gate-Source Breakdown Voltage : 20 V
Package / Case : SOIC-8
Configuration : Dual
Drain-Source Breakdown Voltage : 80 V
Continuous Drain Current : 3.6 A
Resistance Drain-Source RDS (on) : 73 m Ohms


Application

·High frequency DC-DC converters
·Lead-Free


Specifications

  Parameter Max. Units
VDS Drain-to-Source Voltage 80 V
VGS Gate-to-Source Voltage ± 20
ID @ TA = 25 Continuous Drain Current, VGS @ 10V 3.6 A
ID @ TA = 100 Continuous Drain Current, VGS @ 10V 2.9
IDM Pulsed Drain Current 29
PD @TA = 25 Maximum Power Dissipation 2.0 W
dV/dt Peak Diode Recovery 2.3 V/ns
  Linear Derating Factor 0.02 mW/
TJ, TSTG Operating Junction and Storage Temperature Range -55 to + 150



Parameters:

Technical/Catalog InformationIRF7380PBF
VendorInternational Rectifier
CategoryDiscrete Semiconductor Products
Mounting TypeSurface Mount
FET Polarity2 N-Channel (Dual)
Drain to Source Voltage (Vdss)80V
Current - Continuous Drain (Id) @ 25° C3.6A
Rds On (Max) @ Id, Vgs73 mOhm @ 2.2A, 10V
Input Capacitance (Ciss) @ Vds 660pF @ 25V
Power - Max2W
PackagingBulk
Gate Charge (Qg) @ Vgs23nC @ 10V
Package / Case8-SOIC (3.9mm Width)
FET Feature*
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRF7380PBF
IRF7380PBF
