Product Details

Description



Features:

·Resolution: 8 bits (with an overflow output)
·Maximum conversion rate: 20M samples per sec
·Error: Less than ±1.0 LSB
·Power supply: +5-V single-voltage power suppl
·Power dissipation: 150 mW (typical)
·Analog input voltage range: V SSto V DD
·Digital output voltage: 3 state TTL level


Pinout

Connection Diagram


Specifications

Parameter Symbol Conditions Ratings Unit
Maximum supply voltage VDD max   0.3 to +7.0 V
Input voltage VIN max   0.3 to VDD +0.3 V
Operating temperature Topr LC89066 30 to +70
Storage temperature Tstg LC89066M 40 to +125



Description

The LC89086M is a low-power high-speed 8-bit serialparallel A/D converter fabricated in a high-speed CMOS process.
