The LM748 is a general purpose operational amplifier with external frequency compensation.
The unity-gain compensation specified makes the circuit stable for all feedback configurations, even with capacitive loads. It is possible to optimize compensation for best high frequency performance at any gain. As a comparator, the output can be clamped at any desired level to make it compatible with logic circuits.
The LM748C is specified for operation over the 0ßC to a70ßC temperature range.
LM748 Maximum Ratings
Supply Voltage ................................................................................±22V
Power Dissipation (Note 1) ..........................................................500 mW
Differential Input Voltage .................................................................±30V
Input Voltage (Note 2) .....................................................................±15V
Output Short-Circuit Duration (Note 3)
Operating Temperature Range:
LM748C ....................................................................................0 to +70C
Storage Temperature Range ..............................................-65 to +150
Lead Temperature (Soldering, 10 sec.) ............................................+300
Power Dissipation (Note 1) ..........................................................500 mW
Differential Input Voltage .................................................................±30V
Input Voltage (Note 2) .....................................................................±15V
Output Short-Circuit Duration (Note 3)
Operating Temperature Range:
LM748C ....................................................................................0 to +70C
Storage Temperature Range ..............................................-65 to +150
Lead Temperature (Soldering, 10 sec.) ............................................+300
LM748 Features
·Frequency compensation with a single 30 pF capacitor
· Operation from g5V to g20V
· Continuous short-circuit protection
· Operation as a comparator with differential inputs as high as g30V
· No latch-up when common mode range is exceeded
· Same pin configuration as the LM101
