MB91F191A

CPU
• 32-bit RISC (FR series) , load/store architecture, 5-stage pipeline
• General-purpose registers : 16 ´ 32-bit
• 16-bit fixed-length instructions (basic instructions) , 1 instruction per cycle
• Includes memory-to-memory transfer, bit manipulation, and barrel shift instructions :
Optimized for embedded applications
• Includes function entry/exit instructions and multiple-register load/store instructions :
Instruction set supports high level languages
• Register interlock function : For efficient assembly language coding
• Branch instructions with delay slots : Reduced overhead for branch operations
• Internal multiplier unit is supported at instruction level
Signed 32-bit multiplication : 5 cycles
Signed 16-bit multiplication : 3 cycles
• Interrupts (PC and PS saving) : 6 cycles, 16 priority levels

Bus Interface
• 16-bit address output, 8/16-bit data input and output
• Basic bus cycle : 2 clock cycles
• Supports interfaces for various types of memory
• Multiplexed data/address input/output
• Automatic wait cycles : Between 0 and 7 wait cycles can be specified independently for each memory area
• Unused data/address pins can be configured as input/output ports
• Supports little endian mode
Bit Search Module
• Searches, starting from the MSB, for the position of the first 1/0 bit transition in a word. The operation is
performed in one cycle.
Serial I/O
• 3 channels with internal buffer RAM (automatic transfer of up to 128 bytes)
• Independent send and receive buffer mode (automatic transfer of up to 64 bytes)
A/D Converter (Successive Approximation Type)
• 10-bit ´ 16 channels
• Uses successive approximation conversion method (conversion time : 8.4 ms @ 20 MHz)
• Channel scan function
• Hardware and software conversion start functions
• Internal FIFO (Software conversion : 6 stages, Hardware conversion : 6 stages)
Timers
• 16-bit ´ 4 channels
• 16-bit timer/counter ´ 1 channel (with square wave output)
• 8/16-bit timer/counter ´ 1 channel (with square wave output)
FG input unit
• Incorporates capstan, drum, and reel input circuits

Capture unit
• Internal 24-bit free-run counter (Minimum resolution = 50 ns @ 20 MHz)
• Internal FIFO (Data : 21-bit ´ 8, Detection : 8-bit ´ 8)
Programmable pattern generator
• Internal RAM buffer (PPG0 : 256 bytes, PPG1 : 64 bytes)
• Output timing resolution : 800 ns @ 20 MHz
• Includes an A/D converter hardware start function
Realtime timing generator
• RTG : 3 circuits
• Output timing resolution : 400 ns or 800 ns selectable
• Timing output ports : 5 ports
PWM
• 12-bit PWM ´ 6 channels (rate, multi-type)
• Base frequency = 78.1 kHz or 39.0 kHz (@ 20 MHz) selectable

PWC
• 8-bit PWC ´ 1 channel (with mask input)
• Measurement resolution : 400 ns @ 20 MHz
General-purpose prescaler
• 10-bit prescaler ´ 1 channel (with square wave and pulse outputs)
• Dedicated internal oscillator circuit
• Includes load function driven by PPG output
Interrupt control
• External interrupts : 3 inputs
• Key input interrupt : 8 inputs
