MC14011UBD: IC GATE NAND QUAD 2INP 14-SOIC

MC14011UBD Data Sheet

Get Latest Price

Part Number:: MC14011UBD
Mfg:
Supply Ability:: 5000

Price Break

Qty
1~5000

Unit Price
Negotiable

Processing time
15 Days

SeekIC Buyer Protection PLUS - newly updated for 2013!

Escrow Protection.
Guaranteed refunds.
Secure payments.
Learn more >>

Month Sales

268 Transactions

Rating

evaluate (4.8 stars)

Upload time: 2024/4/26

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.

Recent History
What is this?

MC14000UB evaluate
Features: • Diode Protection on All Inputs• Supply Voltage Range = 3.0 Vdc to 18 Vdc&#...
MC14001B evaluate
Features: Supply Voltage Range = 3.0 Vdc to 18 VdcAll Outputs BufferedCapable of Driving Two Low&#...
MC14001BCP evaluate
US $.13 - .13 / Piece

IC GATE NOR QUAD CMOS 14DIP

Product Details

Quick Details

Series:	4000B	Manufacturer:	ON Semiconductor
Logic Type:	NAND Gate	Number of Circuits:	4
Number of Inputs:	2	Features:	-
Voltage - Supply:	3 V ~ 18 V	Current - Quiescent (Max):	1µA
Supply Voltage - Max :	1.9 V	Current - Output High, Low:	3.5mA, 8.8mA
Logic Level - Low:	1 V ~ 2.5 V	Logic Level - High:	4 V ~ 12.5 V
Max Propagation Delay @ V, Max CL:	80ns @ 15V, 50pF	Operating Temperature:	-55°C ~ 125°C
Mounting Type:	Surface Mount	Supplier Device Package:	14-SOICN
Package / Case:	14-SOIC (0.154", 3.90mm Width)

Description

Mounting Type: Surface Mount
Number of Inputs: 2
Features: -
Current - Quiescent (Max): 1µA
Logic Type: NAND Gate
Operating Temperature: -55°C ~ 125°C
Package / Case: 14-SOIC (0.154", 3.90mm Width)
Number of Circuits: 4
Series: 4000B
Voltage - Supply: 3 V ~ 18 V
Logic Level - Low: 1 V ~ 2.5 V
Logic Level - High: 4 V ~ 12.5 V
Packaging: Tube
Manufacturer: ON Semiconductor
Supplier Device Package: 14-SOICN
Max Propagation Delay @ V, Max CL: 80ns @ 15V, 50pF
Current - Output High, Low: 3.5mA, 8.8mA

Parameters:

Technical/Catalog Information	MC14011UBD
Vendor	ON Semiconductor
Category	Integrated Circuits (ICs)
Number of Circuits	4 - Quad
Package / Case	14-SOIC (3.9mm Width), 14-SOL
Logic Type	NAND Gate
Packaging	Tube
Mounting Type	Surface Mount
Number of Inputs	2
Current - Output High, Low	3.4mA, 3.4mA
Supply Voltage	3 V ~ 18 V
Operating Temperature	-55°C ~ 125°C
Voltage - Supply	3 V ~ 18 V
Drawing Number	*
Lead Free Status	Contains Lead
RoHS Status	RoHS Non-Compliant
Other Names	MC14011UBD MC14011UBD
