MC14070BCP

The MC14070B quad exclusive OR gate and the MC14077B quad exclusive NOR gate are constructed with MOS P-channel and N-channel enhancement MC14070B in a single monolithic structure. These complementary MOS logic gates find primary use where low power dissipation and/or high noise immunity is desired.

Features of The MC14070B quad exclusive OR gate and the MC14077B quad exclusive NOR gate  are:(1)Supply Voltage Range = 3.0 Vdc to 18 Vdc;(2)All Outputs Buffered;(3)Capable of Driving Two Low-Power TTL Loads or One Low-Power Schottky TTL Load Over the Rated Temperature Range;(4)Double Diode Protection on All Inputs;(5)MC14070B - Replacement for CD4030B and CD4070B Types;(6)MC14077B - Replacement for CD4077B Type;(7)Pb-Free Packages are Available*.

The absolute maximum ratings of The MC14070B quad exclusive OR gate and the MC14077B quad exclusive NOR gate can be summarized as:(1)DC Supply Voltage Range:-0.5V to +18.0V;(2)Input or Output Voltage Range(DC or Transient):-0.5V to VDD + 0.5V;(3)Input or Output Current(DC or Transient) per Pin:±10mA;(4)Power Dissipation, per Package(Note 1):500mW;(5)Ambient Temperature Range:-55°C to +125°C;(6)Storage Temperature Range:-65°C to +150°C;(7)Lead Temperature(8-Second Soldering):260°C.
