MFG:MC Package Cooled:QFP D/C:03+
MFG: MC
Package Cooled: QFP
D/C: 03+
Description: The Advanced PAL Comb FilterII is a video signal processor for VCRs, LDPs, and TVs. It separates the L...
The Advanced PAL Comb FilterII is a video signal processor for VCRs, LDPs, and TVs. It separates the Luminance Y and Chrominance C signal from the NTSC/PAL composite signal by using digital signal processing techniques which minimize dotcrawl and crosscolor. The builtin 4xFSC PLL circuit allows a subcarrier signal input, which generates 4xFSC clock for video signal processing. This filter allows a video signal input of an extended frequency bandwidth by using a 4xFSC clock. The builtin vertical enhancer circuit reduces noise and dot crawl on the Luminance Y signal. The builtin A/D and D/A converters allow easy connection to analog video circuits.
|
Characteristic |
Symbol |
Value |
Unit |
| DC Supply Voltage (Referenced to GND) |
VCC |
0.5 to + 7.0 |
V |
|
DC Input Voltage (Referenced to GND) |
Vin |
1.5 to VCC + 1.5 |
V |
| DC Output Voltage (Referenced to GND) |
Vout |
0.5 to VCC + 0.5 |
V |
| DC Input Current (per pin) |
Iin |
± 20 |
mA |
| DC Output Current (per pin) |
Iout |
± 25 |
mA |
| Power Dissipation |
PD |
750 |
mW |
| Storage Temperature Range |
Tstg |
65 to + 150 |
MC141627/D
PDF/DataSheet Download
