MFG:MOT Package Cooled:QFP
MFG: MOT
Package Cooled: QFP
Description: The Advanced PAL Comb FilterII is a video signal processor for VCRs, LDPs, and TVs. It separates the L...
The Advanced PAL Comb FilterII is a video signal processor for VCRs, LDPs, and TVs. It separates the Luminance Y and Chrominance C signal from the NTSC/PAL composite signal by using digital signal processing techniques which minimize dotcrawl and crosscolor. The builtin 4xFSC PLL circuit allows a subcarrier signal input, which generates 4xFSC clock for video signal processing. This filter allows a video signal input of an extended frequency bandwidth by using a 4xFSC clock. The builtin vertical enhancer circuit reduces noise and dot crawl on the Luminance Y signal. The builtin A/D and D/A converters allow easy connection to analog video circuits.
| Symbol | Parameter | Value | Unit |
| VCC | DC Supply Voltage (Referenced to GND) | 0.5 to + 7.0 | V |
| Vin | DC Input Voltage (Referenced to GND) | 1.5 to VCC + 1.5 | V |
| Vout | DC Output Voltage (Referenced to GND) | 0.5 to VCC + 0.5 | V |
| Iin | DC Input Current (per Pin) | ± 20 | mA |
| Iout | DC Output Current (per Pin) | ± 25 | mA |
| PD | Power Dissipation | 750 | mW |
| Tstg | Storage Temperature Range | 55 to +150 |
°C |
MC141627FT
PDF/DataSheet Download
The Advanced PAL Comb FilterII is a video signal processor for VCRs, LDPs, and TVs. MC141627 separates the Luminance Y and Chrominance C signal from the NTSC/PAL composite signal by using digital signal processing techniques which minimize dotcrawl and cross...
The MC141622EVK is a development board for evaluation of the MC141622. In addition to the MC141622, the MC141622EVK contains all the analog circuit that is necessary for buffering both the input and output video signal and generation of the 4xfsc clock. By c...
The Advanced Comb FilterII is a video signal processor for VCRs and TVs.MC141622'sfunction is to separate the Luminance Y and Chrominance C signals from the NTSC composite video signal. The ACFII minimizes dotcrawl and crosscolor. A builtin PLL provides a 4x...
