General Description
MC68HC908GZ60 General Description
The MC68HC908GZ60, MC68HC908GZ48, and MC68HC908GZ32 are members of the low-cost, high-performance M68HC08 Family of 8-bit microcontroller units (MCUs). All MCUs in the family use the enhanced M68HC08 central processor unit (CPU08) and are available with a variety of modules, memory sizes and types, and package types.
The information contained in this document pertains to all three devices with the exceptions noted in Appendix A. MC68HC908GZ48 and Appendix B. MC68HC908GZ32.
MC68HC908GZ60 Maximum Ratings
Maximum ratings are the extreme limits to which the MCU can be exposed without
permanently damaging it.
NOTE: This device is not guaranteed to operate properly at the maximum ratings. Refer to
21.5 5.0-Vdc Electrical Characteristics for guaranteed operating conditions.
|
Characteristic(1) |
Symbol |
Value |
Unit |
|
Supply voltage |
VDD |
0.3 to + 6.0 |
V |
|
Input voltage |
VIn |
VSS 0.3 to VDD + 0.3 |
V |
|
Maximum current per pin excluding those specified below |
I |
± 15 |
mA |
|
Maximum current for pins PTC0PTC4 |
IPTC0PTC4 |
± 25 |
mA |
|
Maximum current into VDD |
Imvdd |
150 |
mA |
|
Maximum current out of VSS |
Imvss |
150 |
mA |
|
Storage temperature |
Tstg |
55 to +150 |
°C |
1. Voltages referenced to VSS
NOTE: This device contains circuitry to protect the inputs against damage due to high static voltages or electric fields; however, it is advised that normal precautions be taken to avoid application of any voltage higher than maximum-rated voltages to this high-impedance circuit. For proper operation, it is recommended that VIn and VOutbe onstrained to the range VSS (VIn or VOut) VDD. Reliability of operation is enhanced if unused inputs are connected to an appropriate logic voltage level (for example, either VSS or VDD).
MC68HC908GZ60 Features
For convenience, features have been organized to reflect:
• Standard features
• Features of the CPU08
• Standard features
• Features of the CPU08
MC68HC908GZ60 Connection Diagram
