Part Number: NMA2415D
MFG: 2000
Description: The NMA series of DC-DC converters are the standard building blocks for on-board distributed power sys...
- Table of contents:
NMA2415D
-
Suppliers
DataSheet
General Description
NMA2415D General Description
The NMA series of DC-DC converters are the standard building blocks for on-board distributed power systems. They are ideally suited to providing dual rail supplies on primarily digital boards with the added benefit of galvanic isolation to reduce switching noise. All of the rated power may be drawn from a single pin provided the total load does not exceed 1 Watt.
NMA2415D Maximum Ratings
Short-circuit duration3 . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 second
Lead temperature 1.5mm from case for 10 seconds . . . . . . 300°C
Input voltage VIN, NMA24 types . . . . . . . . . . . . . . . . . . . . . . . . 28V
Input voltage VIN, NMA48 types . . . . . . . . . . . . . . . . . . . . . . . . 54V
1 Calculated using MIL-HDBK-217F with nominal input voltage at full load.
2 See derating curve
3 Supply voltage must be discontinued at the end of the short circuit duration.
All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified.
Lead temperature 1.5mm from case for 10 seconds . . . . . . 300°C
Input voltage VIN, NMA24 types . . . . . . . . . . . . . . . . . . . . . . . . 28V
Input voltage VIN, NMA48 types . . . . . . . . . . . . . . . . . . . . . . . . 54V
1 Calculated using MIL-HDBK-217F with nominal input voltage at full load.
2 See derating curve
3 Supply voltage must be discontinued at the end of the short circuit duration.
All specifications typical at TA=25°C, nominal input voltage and rated output current unless otherwise specified.
NMA2415D Features
· Dual Output from a Single Input Rail
· Industry Standard Pinout
· Power Sharing on Output
· 1kVDC Isolation
· Efficiency to 80%
· Power Density 0.85W/cm3
· 24V & 48V Input
· 5V, 9V, 12V and 15V Output
· Footprint from 1.17cm2
· UL 94V-0 Package Material
· No Heatsink Required
· Internal SMD Construction
· Toroidal Magnetics
· Fully Encapsulated
· No External Components Required
· Custom Solutions Available
· Industry Standard Pinout
· Power Sharing on Output
· 1kVDC Isolation
· Efficiency to 80%
· Power Density 0.85W/cm3
· 24V & 48V Input
· 5V, 9V, 12V and 15V Output
· Footprint from 1.17cm2
· UL 94V-0 Package Material
· No Heatsink Required
· Internal SMD Construction
· Toroidal Magnetics
· Fully Encapsulated
· No External Components Required
· Custom Solutions Available
